Manufacture Schmutz / 1974   Line Speed 1000 fpm max   Strip Thickness .020" max   Strip Width 60" max   Coil Size 40" OD, 3-9" ID   Equipment   - Uncoiler Cone type, brake tension   Centering and lateral adjust   10" ID x 44" face drums   20" ID x 60" face drums - Slitter 440VDC/3/60   Much tooling - Recoiler 3",6",9",10",12",16" mandrels   50hp, 500/2000rpm, 240VDC motor Sold "as is, where is" installed, USA
